Total Station Topcon GM 52

Jual Total Station Topcon GM 52 High Quality, High Return!

  • Construction and Survey Application Software
  • Fast & Accurate & Powerful Measuring Distance Feature
  • 500m Long Range Reflectoress Measurement
  • Rugged & Waterproof Design
  • Reliable Large Volume Internal Memory



SKU: GM52 Category:

Jual Total Station Topcon GM 52

Jual Total Station Topcon GM 52  2 Detik sebuah alat survey yang berfungsi untuk pemetaan dan kontruksi bangunan atau pengukuran lahan tambang dll dan total station merupakan alat yang terinclude dengan theodolite dan komponen untuk pengukur jarak electronik atau bisa di sebut dengan electronic distance meter (EDM).

Total Station Topcon GM 52 Fast and Powerful Reflectorless EDM

  • Fast and accurate pinpointing with phase shift technology.
  • Fast distance measurement of 0.9s regardless of object.
  • Minimum reflectorless measuring distance – just 30cm.
  • Improved collimation with super-bright pointer.
  • Smaller EDM beam spot size for minimal distance
    measuring error.
  • Dependable measuring even at shallow incidence angles.
  • Ensures accurate reflective sheet distance measurement.

jual total station topcon gm 50 52 55

Total Station Topcon GM 52 High Quality, High Return!

  • Construction and Survey Application Software
  • Fast & Accurate & Powerful Measuring Distance Feature
  • 500m Long Range Reflectoress Measurement
  • Rugged & Waterproof Design
  • Reliable Large Volume Internal Memory

Spesifikasi Total Station Topcon GM 50 Series

ModelGM-52GM-55
Telescope
Magnification / Resolving power 30x / 2.5″
OthersLength : 171mm (6.7in.), Objective aperture : 45mm (1.8in.) (48mm
(1.9in.) for EDM), Image: Erect, Field of view: 1°30′ (26m/1,000m),
Minimum focus: 1.3m (4.3ft.) Reticle illumination: 5 brightness levels
Angle measurement
Minimum Display1”/5” (0.0002 / 0.001gon, 0.005 / 0.02mil)
Accuracy (ISO 17123-3:2001)2″ 5″
Dual-axis compensator /Dual-axis liquid tilt sensor, working range: ±6′
Collimation compensationOn/Off (selectable)
Distance measurement
Laser output*1Reflectorless mode : Class 3R / Prism/sheet mode : Class 1
Measuring range     Reflectorless*30.3 to 500m (1,640ft.)
(under average       Reflective sheet*4*5RS90N-K: 1.3 to 500m (4.3 to 1,640ft.),
conditions*2)RS50N-K: 1.3 to 300m (4.3 to 980ft.),
RS10N-K: 1.3 to 100m (4.3 to 320ft.)
Mini prism
One prism
1.3 to 500m (4.3 to 1,640ft.)
1.3 to 4,000m (4.3 to 13,320ft)
Minimum Display                                   Fine / Coarse : 0.0001m (0.001ft. / 1/8 in.) / 0.001m (0.005ft. / 1/8 in.) (selectable)
Coarse : 0.001m (0.005ft. / 1/8 in.) / 0.01m (0.02ft. / 1 in.) (selectable)
Tracking / Road : 0.01m (0.02ft. / 1 in.)
Accuracy*2                         Reflectorless*3(2 + 2ppm x D) mm*6
(ISO 17123-4:2001) Reflective sheet*4*5(2 + 2ppm x D) mm
(D=measuring distance in mm)     Prism*7(1.5 + 2ppm x D) mm
Measuring time*8         Fine0.9s (initial 1.5s)
Coarse0.6s (initial 1.3s)
Tracking0.4s (initial 1.3s)
OS, Interface and Data management
Operating systemLinux
Display / KeyboardGraphic LCD, 192 x 80 dots, backlight : on/off (Selectable) /
Alphanumeric keyboard / 28 keys with backlight
Control panel locationOn both faces                          On single face
Data storage          Internal memory
Plug-in memory device
Approx. 50,000 points
USB flash memory (max. 32GB)
InterfaceSerial RS-232C, USB2.0 (Type A for USB flash memory)
Bluetooth modem (option)*9Bluetooth Class 1.5, Operating range: up to 10m *10

Total Station Topcon GM 52 Japan Quality Products

Kami melakukan uji lingkungan yang sulit untuk memastikan alat survey bisa beroperasi jangka panjang bahkan di bawah lingkungan situs yang kasar.
Total Station Topcon GM 50 Series diperiksa secara menyeluruh dengan ruang uji tahan debu dan tahan air.
Selain itu, berbagai tes terhadap getaran, penurunan, suhu, dan kelembapan berhasil dilewati untuk mencapai spesifikasi lingkungan terbaik. Juga, uji akurasi jarak pengukuran pada garis dasar dan uji leveling instrumen dan akurasi sudut dan penyesuaian dengan sistem kolimator memastikan kepuasan Anda terhadap kualitas produk Seri GM.

Download Brosur Spesifikasi Jual Total Station Topcon GM 52 2 Detik  Lengkapnya >> KLIK DISINI <<

Jual Total Station Topcon GM 52  dengan Akurasi 2 Detik dengan harga murah, dapatkan diskon dan cari produk TOPCON lainnya di kategori Total Station. Gratis ongkos pengiriman Jakarta dan bisa dikirim ke seluruh Indonesia. Dapatkan hanya di toko online www.akurasimisisurvey.co.id, melakukan pembelian barang alat survey online gampang dan aman.
